Double Electromagnetic Lock , 2200Lbs, 1000Kgs

Double Electromagnetic Lock , 2200Lbs, 1000Kgs

Click here for details.

Double Electromagnetic Lock , 2200Lbs, 1000Kgs

Product ID: PML-4100 / PML-4101

Send Inquiry
•2200Lbs (1000Kgs) holding force electromagnetic & magnetic lock.

•For access control systems with high traffic doors which are fail-safe operation.

•The locks contain none of moving parts and there are maintenance free and durable.

•Additionally, door position contacts and LED indication for correct alignment of armature are available for some versions.
Specifications
  • PML-4100
    • *Magnet size (mm):532(L) x 73(W) x 40(D)
    • *Armature size (mm):185(L) x 61(W) x 16(D)
    • *Holding force: 2200Lbs /1000kgs
    • *Voltage/Current:12V/1000mA, 24V/500mA
    • *Voltage tolerance:10%
    • *Relay dry contact rating:500mA ,24VDC/AC
    • *Unit weight (Approx.): 11.0kg
  • PML-4101
    • *Magnet size (mm):532(L) x 73(W) x 40(D)
    • *Armature size (mm):185(L) x 61(W) x 16(D)
    • *Holding force: 2200Lbs /1000kgs
    • *Voltage/Current:12V/1000mA, 24V/500mA
    • *Voltage tolerance:10%
    • *Relay dry contact rating:500mA 24VDC/AC
    • *Unit weight (Approx.): 11.0kg
    • *Door monitoring: YES
    • *Timer (LED): YES
  • We reserve the right to change the specification without notice or obligation!
