Specifications
- Dual Input Voltage: 115/230 VAC, 50/60 HZ Single Phase
- Dual Output Voltage: 0-90/0-180V DC PM Motors
- Horsepower Range: 1/20-1HP 115 VAC, 1/10-2HP 230VAC
- Speed Regulation: 1% of Rate (Typical)
- Speed Range: 50:1 Constant Torque
- Full Wave Rectification
- Minimum Speed Adjustment: Sets low and speed limit
- Maximum Speed Adjustment: Sets high end speed limit
- Regulation adjustment: Adjustable no load to full load RPM
- Torque (Current Limit): Adjustable maximum current cut-off
- Current select switch: more exactly to set current
- Accel / Decel Trim Adjustment: 0.5 to 40 sec
- Built-in Fuse Holders
- Built-in Transient and Surge Protection
- Built-in Line Voltage Compensation
- Additional heatsinking only required for 3/4 HP and 1 HP 115 V AC, 1 1/2 HP and 2 HP 230 V AC
Part No. | Description |
---|---|
QS-800A (1/20HP - 1/4HP) | Basic Controll |
QS-800B (1/4HP - 2HP) | Basic Controll |
P800 | VR, Knob, Teminal |
