Axial AC Fan - SJ9225

Axial AC Fan - SJ9225

Click here for details.

AC Fan

Product ID: SJ9225HA2SAT (L)

Send Inquiry
  • There are 8 product ID in Sanju product series of SJ9225, SJ9225HA2SAT is a 220V AC Fan with 92mm aluminum square frame , 25mm thickness, plastic blade, sleeve bearing, high air speed, and provide 2.90mm faston to connected with the power supply. SJ9225HA2SAL is the same funtion fan but with leadwire connect type.



Model Part No. Bearing System Rated Voltage Freq. Current Input Power Speed Air Flow Static Pressure Noise Level
( V ) ( Hz ) ( A ) ( W ) (RPM) (m3/min) (lnch-H2 o) (db-A)
SJ9225 SJ9225HA1BAT (L) Ball 110/120V 50/60 0.14/0.12 12/9 2600/3100 0.93/1.13 0.18/0.26 32/36
SJ9225HA1SAT (L) Sleeve 110/120V 50/60 0.14/0.12 12/9 2600/3100 0.93/1.13 0.18/0.26 32/36
SJ9225HA2BAT (L) Ball 220/240V 50/60 0.07/0.06 13/10 2500/3000 0.93/1.13 0.18/0.26 32/36
SJ9225HA2SAT (L) Sleeve 220/240V 50/60 0.07/0.06 13/10 2500/3000 0.93/1.13 0.18/0.26 32/36
SJ9225LA1BAT (L) Ball 110/120V 50/60 0.14/0.12 12/9 1900/2400 0.57/0.70 0.10/0.14 27/31
SJ9225LA1SAT (L) Sleeve 110/120V 50/60 0.14/0.12 12/9 1900/2400 0.57/0.70 0.10/0.14 27/31
SJ9225LA2BAT (L) Ball 220/240V 50/60 0.07/0.06 13/10 1800/2400 0.27/0.70 0.10/0.14 27/31
SJ9225LA2SAT (L) Sleeve 220/240V 50/60 0.07/0.06 13/10 1800/2400 0.27/0.70 0.10/0.14 27/31
Specifications
  • Square Frame : 92 mm * 92 mm
  • Housing Thickness : 25 mm
  • Bearing System : Sleeve
  • Rated Vottage(V) : 220 / 240
  • Freq.(hz) : 50 / 60
  • Current(A) : 0.07 / 0.06
  • Input Power(W) : 13 / 10
  • Speed(RPM) : 2500 / 3000
  • Air Flow(m3/min) : 0.93 / 1.13
  • Static Pressure(lnch-H2 o) : 0.18 / 0.26
  • Noise Level(db-A) : 32 / 36
Certificate
  • CE
  • TUV -LVD
  • TUV-EMC
  • UL
  • cUL
  • CCC
