Specifications
.We reserve the right for any alteration without prior notice.Features
- Maintenance of a constant welding amplitude and welding result even during fluctuation in the supply of voltage.
- LED indication and buzzer warning in case of any circuit trouble-easy warning.
- Optional LED indication for sonic adjustment-easy sonic adjustment.
- LED indication for trouble position, only new fuse to be replaced-easy maintenance.
- Roller guide rail (10 times stronger than steel balls)-easy for up and down strokes.
- Possible to control a height range within +-0.01m to weld with constant weld travel and set energy and time limits.
- Robust large bed, more stable, suitable for large size dies.
- Electronic dynamic overload protection.
- Electronic protection for transducer and power transistor.
- PC panel design for easy cleaning.
- Integral unit, nice appearance, easy adjustment.
- Environment friendly green color painting.
- Power:
- 220V x 1P x 50HZ
- 220V x 1P x 60HZ
- Air: 0.5 ~ 9 kg/cm2
| MODEL NO | FREQUENCY | OUTPUT | A | WELDING(ABS) | DIMENSIONS(CM) | NET WEKTHT | WORKING HEIGHT |
|---|---|---|---|---|---|---|---|
| STP-2013P | 20KHZ | 1300W | 10 | 60 dia | 80 x 60 x 140 | 90 | 0~320 m/m |
| STP-2015P | 20KHZ | 1500W | 10 | 80 dia | 80 x 60 x 140 | 90 | 0~320 m/m |
| STP-2020P | 20KHZ | 2000W | 12 | 100 dia | 80 x 60 x 140 | 100 | 0~320 m/m |
| STP-2025PCB | 20KHZ | 2500W | 12 | 120 dia | 80 x 60 x 140 | 100 | 0~320 m/m |
| STP-1518P | 15KHZ | 1800W | 10 | 150 dia | 80 x 60 x 140 | 110 | 0~320 m/m |
| STP-1522P | 15KHZ | 2200W | 12 | 170 dia | 80 x 60 x 140 | 110 | 0~320 m/m |
| STP-1528P | 15KHZ | 2800W | 12 | 180 dia | 80 x 60 x 140 | 120 | 0~320 m/m |
| STP-1532HP | 15KHZ | 3200W | 15 | 200 dia | 110 x 60 x 210 | 250 | 0~320 m/m |
| STP-1536HP | 15KHZ | 3600W | 15 | 230 dia | 110 x 90 x 210 | 250 | 0~320 m/m |
| STP-1542HP | 15KHZ | 4200W | 15 | 250 dia | 110 x 90 x 210 | 250 | 0~320 m/m |
