Maintain constant oil temperature.
Prevent oil deterioration. Maintain oil viscosity ensures smooth and stable oil pressure.
Built-in safety protection devices ensure no sudden breakdown.
Computer controlled sensors adjust oil temperature according to the ambient temperature ensure precision in machining processes.
Prevent oil deterioration. Maintain oil viscosity ensures smooth and stable oil pressure.
Built-in safety protection devices ensure no sudden breakdown.
Computer controlled sensors adjust oil temperature according to the ambient temperature ensure precision in machining processes.
Features
- Application
- CNC machine center
- CNC grinder. Broach machine
- CNC carve wood machine. Oil pressure machine
- CNC lathe. High-speed lathe
- Sample Purchase
| Model | N/A | CO-4 | CO-6 | CO-8 | CO-12 | CO-18 | CO-24 | CO-36 | CO-60 | CO-120 |
|---|---|---|---|---|---|---|---|---|---|---|
| Cooling capacity | Kcah/h | 1,000 | 1,750 | 2,500 | 3,000 | 4,500 | 6,000 | 9,000 | 1,5000 | 3,0000 |
| Cooling capacity | BTU/H | 4,000 | 7,000 | 10,000 | 12,000 | 18,000 | 24,000 | 36,000 | 60,000 | 120,000 |
| Power source | V | MAIN CIRCUIT 3 Dia 200V 50/60HZ CIRCUIT 1 Dia AC24V | MAIN CIRCUIT 3 Dia 200V 50/60HZ CIRCUIT 1 Dia AC24V | MAIN CIRCUIT 3 Dia 200V 50/60HZ CIRCUIT 1 Dia AC24V | MAIN CIRCUIT 3 Dia 200V 50/60HZ CIRCUIT 1 Dia AC24V | MAIN CIRCUIT 3 Dia 200V 50/60HZ CIRCUIT 1 Dia AC24V | MAIN CIRCUIT 3 Dia 200V 50/60HZ CIRCUIT 1 Dia AC24V | MAIN CIRCUIT 3 Dia 200V 50/60HZ CIRCUIT 1 Dia AC24V | MAIN CIRCUIT 3 Dia 200V 50/60HZ CIRCUIT 1 Dia AC24V | MAIN CIRCUIT 3 Dia 200V 50/60HZ CIRCUIT 1 Dia AC24V |
| Total overburdening current | A | 5 | 7.5 | 7.5 | 10 | 11.4 | 9.5 | 12.7 | 21 | 40 |
| Oil pump horsepower | HP | 1/4 | 1/2 | 1/2 | 1 | 1 | 1 | 1 | 1 | 2 |
| Oil pump discharge rate | I/min | 4.5/7.5 | 12 | 12/20 | 30 | 30 | 30 | 30/40 | 60 | 60 |
| Pipe size | inch | 1/2" x 1/2" | 3/4" x 3/4" | 3/4" x 3/4" | 1" x 1" | 1" x 1" | 1" x 1" | 1" x 1" | 1 1/4" x 1 1/4" | 1 1/2" x 1 1/2" |
| Cooling medium | R | 134A/22 | 134A/22 | 22 | 22 | 22 | 22 | 22 | 22 | 22 |
| Dimension (D x W x H) | mm | 360 x 440 x 640 | 460 x 400 x 760 | 433 x 533 x 825 | 550 x 480 x 940 | 490 x 690 x 1,155 | 490 x 690 x 1,155 | 690 x 805 x 1,155 | 790 x 900 x 1,285 | 790 x 1,270 x 1,890 |
| Weight | Kg | 59 | 86 | 105 | 110 | 125 | 130 | 145 | 310 | 360 |
