Prevent corrosion, and rust formation.
Increased paint color brilliance. No bubbles.
Prevent refraction mirror breakage caused by laser.
Improved heat exhaustion.
Increased paint color brilliance. No bubbles.
Prevent refraction mirror breakage caused by laser.
Improved heat exhaustion.
Features
- Application
- Machine pneumatic tool
- Medical appliances
- Paint, laser cutting machine
- High-speed drive axle
- Sample Purchase
Model | N/A | CAD-5A | CAD-10A | CAD-20A | CAD-30A | CAD-50A | CAD-75A | CAD-100A |
---|---|---|---|---|---|---|---|---|
Air compressor | HP | 0-5 | 5-10 | 10-20 | 20-30 | 30-50 | 50-75 | 75-100 |
Compressed air value | NM^3/min | 0.7 | 1.5 | 2.4 | 4 | 6.5 | 9 | 13 |
In-air temperature range | deg C | 5-45 deg C | 5-45 deg C | 5-45 deg C | 5-45 deg C | 5-45 deg C | 5-45 deg C | 5-45 deg C |
In-room temperature range | degC | 5-45 deg C | 5-45 deg C | 5-45 deg C | 5-45 deg C | 5-45 deg C | 5-45 deg C | 5-45 deg C |
Temperature of compressed air | Kg/cm^2 | 7 | 7 | 7 | 7 | 7 | 7 | 7 |
Cooling capacity | BTU/HR | 3,000 | 4,000 | 7,000 | 13,000 | 18,500 | 24,000 | 36,000 |
Cooling medium | CFC | R-22 | R-22 | R-22 | R-22 | R-22 | R-22 | R-22 |
Power Source | V | 1 Dia AC220V 50/60HZ | 1 Dia AC220V 50/60HZ | 1 Dia AC220V 50/60HZ | 1 Dia AC220V 50/60HZ | 1 Dia AC220V 50/60HZ | 1 Dia AC220V 50/60HZ | 1 Dia AC220V 50/60HZ |
Install & pipe | inch | 1/2" x 1/2" | 3/4" x 3/4" | 1" x 1" | 1" x 1" | 1 1/2" x 1 1/2" | 1 1/2" x 1 1/2" | 2" x 2" |
Total consume | KW | 0.5 | 0.7 | 0.8 | 1.2 | 1.8 | 2 | 2.7 |
Evaporator | SUS | SUS 304 Heat Exchanger | SUS 304 Heat Exchanger | SUS 304 Heat Exchanger | SUS 304 Heat Exchanger | SUS 304 Heat Exchanger | SUS 304 Heat Exchanger | SUS 304 Heat Exchanger |
Auto drain machine | N/A | Fioat Ball | Fioat Ball | Fioat Ball | Fioat Ball | Fioat Ball | Fioat Ball | Fioat Ball |
Dimension (D x W x H) | mm | 190 x 450 x 450 | 260 x 520 x 760 | 310 x 630 x 820 | 310 x 630 x 820 | 330 x 820 x 890 | 575 x 955 x 910 | 575 x 955 x 910 |
Main Products
Oil cooler series, Specific for machine tools, Air conditioners for electrical control panels, Water cooler series specific FRO CNC laser cutting engraver system, Water cooler, Cooling air dryer
