Veneer Cutting Machine (Single Pulling)

Veneer Cutting Machine (Single Pulling)

Click here for details.

Veneer Cutting Machine (Single Pulling)

Product ID: CH-660, CH-720, CH-940, CH-1060, CH-1210, CH-1510, CH-1660

Send Inquiry

Movie:

https://youtu.be/VNHebEEyr3s

Micro-Computer use 7"Color Touch Screen

˙Micro-computer controlled 7"color touch screen, 100 set micro computer control. Automatic display Backgauge position, Memory 2,000 point.

Features
  • Cutting blade driven by worm wheel and magnetic clutch.
  • Photo-sensor for safety.
  • The back guard equip with linear bearing for smooth movement, exact position-setting , wearing endurance
  • Labor-saving, quickly structure for change Knife
    • Lifting knife by the mechanism principle to change the knife efficiently and safely.
  • Optical cutting line correct cutting position
  • Work table slot is cover by the belt , avoid the paper dust drop into the slot.
  • Specially designed powerful electro-magnetic brake clutch avoids accidental second- time knife cutting
  • Cutting use : veeneer, suitable for paper, cardboard, corrugated paper, thin plastics(PVC, PE, PP, PU), leather slice, slice fiber cloth, thin glass, clothes, cork, etc.
  • Metric, Taiwanese, and British system of computerized, measure setting for your free options.
Spec/Model CH-660 CH-720 CH-940 CH-1060 CH-1210 CH-1510 CH-1660
Cutting Thickness 120mm 120mm 135mm 135mm 135mm 135mm 135mm
Cutting Width 660mm 720mm 940mm 1060mm 1210mm 1510mm 1660mm
Cutting Length 660mm 720mm 940mm 1060mm 1210mm 1420mm 1660mm
Front Table Length 540mm 540mm 630mm 630mm 630mm 630mm 630mm
Table Height 820mm 820mm 860mm 860mm 860mm 860mm 860mm
Total Machine Length 1720mm 1780mm 2160mm 2340mm 2600mm 2800mm 2820mm
Machine Width 1510mm 1570mm 2160mm 2450mm 2500mm 3020mm 3200mm
Machine Height 1470mm 1470mm 1500mm 1560mm 1800mm 1800mm 1800mm
Electrical Supply (Dia./N) φ3/220V φ3/220V φ3/220V φ3/220V φ3/220V φ3/220V φ3/220V
Net Weight (kg) 1500kg 1550kg 2200kg 2400kg 3500kg 4000kg 4700kg
Main Motor 1HP 1HP 3HP 3HP 5HP 5HP 5HP
Hydraulic Motor 1HP 1HP 2HP 2HP 3HP 3HP 3HP

Paper Feeding Moto

1HP 1HP 1HP 1HP 1HP 1HP 1HP
