EDI-LB-WP30x/27T

Features & Benefits:
1> IP68, waterproof for your both indoor and outdoor applications;
2> Easily connected and installed with accessories, maintenance free;
3> Long life span of more than 50,000 hours;
4> Consist of ultra bright LEDs in high intensity and can emit higher brightness at lower cost;
5> Maintain all of their LED's to the tightest color tolerances to produce even color from strip to strip;
6> Safety and stable with 12VDC low voltage;
7> Energy saving with low power consumption

Physical Specs:
1> Dimmension: L500 x W18 x H15mm for LB-30x, L440 x W18 x H15mm for LB-27T
2> LED spacing: 16mm
3> IP Rating: IP68
4> Working Temperature: -40~40℃

Electric and Optic Specs:
1> Voltage: 12VDC
2> Current: 20mA
3> Wattage: 2.4Watt
4> Max connection in one loop: 12pcs
5> Viewing angle: 90 degree
6> Color available: Red/Yellow/Blue/Green/White/Warm White/RGB



EDI-LB-SMD30x&30T

Features & Benefits:
1> Rigid and nice outlooking strip with anodized aluminum base;
2> Slim size, with thickness 7mm only;
3> IP68, waterproof for your both indoor and outdoor applications;
4> Easily connected and installed with accessories, maintenance free;
5> Long life span of more than 50,000 hours;
6> Safety and stable with 12VDC low voltage;
7> Energy saving with low power consumption

Physical Specs:
1> Dimmension: L580 x W12 x H7mm / 30pcs LEDs
2> LED spacing: 19mm
3> IP Rating: IP68
4> Working Temperature: -40~40℃

Electric and Optic Specs:
1> Voltage: 12VDC
2> Current: 60mA
3> Wattage: 7.2Watt
4> Max connection in one loop: 8pcs
5> Viewing angle: 120 degree
6> Color available: Red/Yellow/Blue/Green/White/Warm White/RGB
