Specifications

• main specifications
• Main Functions:
• 1. pan/tilt control
• 2. supports UPnP, plug and view
• 3. dynamic domain name analysis
• 4. IE monitoring
• 5. assign dynamic IP address
• Specifications:
• Image System
• - Compression: JPEG Standard
• - 300,000 pixels CMOS sensor
• - 6.0mm, CS mount lens
• - Mini. Illumination: 2.0 Lux@550nm
• - Automatic White Balance
• - Resolution:
• QVGA (320 x 240), VGA (640 x 480)
• - Image Frame Rate:
• Max. 30 fps at QVGA, 15 fps at VGA
• Network Interface
• - RJ-45 for Ethernet
• Network Protocols
• - TCP/IP, FTP, SMTP, HTTP, UDP, DHCP, NTP, DDNS, UPNP, DNS, PPPoE
• Monitor Method
• - IE6.0 or above
• Software upgrade
• - Systematic software & web page upgrade
• Security
• - Three-level Password Protection
• Alarm
• - Triggered by: Motion Detection/ close trigger
• - Action: FTP image to remote site; E-mail image to specific account;
• - Output: 1 Ch (5VDC, 0.1A); Input: 1 Ch (close trigger)
• Pan/Tilt Control
• - Vertical: 90? Horizontal: 120
• Mechanical & Environment
• - Dimensions: 110x110x100mm
• - Weight: 0.6kg (including the package and power adaptor)
• - Power supply: 110-220VAC/5VDC, 1A
• - Operation Environment: 0蚓 to 50蚓 (32 F to 122 F), 20%-80%RH
