Features
- More than 500 mold tooling available
- Durability and low cost
- Largely used in the electric and electronic field like DC motor and loudspeaker
- Excellent and High Quality Control
| Property Grade | Br KG T(Nor./Min.) | bHc Koe KA/m(Nor./Min.) | iHc Koe KA/m(Nor./Min.) | BHmax MGOe KJ/m(Nor./Min.) | MMPA Equivalent Standard | Application |
|---|---|---|---|---|---|---|
| F-330 | 3.80~3.60 / 0.38~0.36 | 2.40~1.90 / 191~151 | 2.50~2.00 / 200~159 | 3.50~3.00 / 27.9~23.9 | Ceramic3 | Loud-speaker |
| F-330C | 3.70~3.40 / 0.37~0.34 | 3.65~3.35 / 291~267 | 4.15~3.85 / 330~306 | 3.30~2.90 / 26.3~23.1 | Ceramic7 | DC motor |
| F-340N | 3.90~3.70 / 0.39~0.37 | 3.05~2.65 / 243~211 | 3.10~2.70 / 247~215 | 3.60~3.20 / 28.7~25.5 | N/A | DC motor |
| F-360 | 4.10~3.80 / 0.41~0.38 | 2.50~2.00 / 200~159 | 2.60~2.20 / 207~175 | 3.80~3.30 / 30.2~26.3 | Ceramic5 | Loud-speaker |
| F-380H | 3.90~3.70 / 0.39~0.37 | 3.60~3.30 / 287~263 | 3.90~3.50 / 310~279 | 3.70~3.30 / 29.5~26.3 | N/A | DC motor |
| F-400H | 4.10~3.90 / 0.41~0.39 | 3.20~3.00 / 287~239 | 3.40~3.10 / 271~247 | 4.00~3.60 / 31.8~287 | Ceramic8 | DC motor |
| F-410C | 4.10~3.70 / 0.41~0.37 | 3.90~3.60 / 310~286 | 4.10~3.80 / 326~302 | 4.10~3.70 / 32.6~29.6 | N/A | DC motor |
| F-420 | 4.30~4.00 / 0.43~0.40 | 3.10~2.80 / 248~223 | 3.30~2.90 / 264~231 | 4.30~4.00 / 34.4~31.8 | N/A | Generator |
Main Products
Ferrite ceramic, Roue Earth Magnet, Bonded Magnet, Car Waxer/Polisher DC Massage Machine DC Motor, Noodle Machine AC Motor
