Detailed specification of connected container buildings
Size 5950mm(L)*2250mm (W)*2690 mm(H)(external size) 5700mm(L)*2020mm(W)*2390mm(H)(internal size)
Or6050mm(L)*2438mm (W)*2590 mm(H)(external size) 5875mm(L)*2255mm(W)*2325mm(H)(internal size)
Floor Composition external/internal wainscot: Flat galvanized coated metal sheet in the thickness of 0.5 mm
(Zn coating 180g/m2) and painted (Top side 10 μm) Steel sheet metal, in ASTM A653 CS
quality;insulation filling: mineral wool in a thickness of 100 mm (EN 13162, reaction to fire acc. to
EN 13501 Class 1) among steel transverse supports;steam blockade: PE foil in a thickness of 80 μm;
waterproof chipboard in a thickness of 22 mm – E1 (EN 120), type P5 ( EN 312);
glued final PVC floor covering in a thickness of 1,5 mm (EN 649),
Grey color with welded connections.
Ceiling Composition external/Internal wainscot: flat galvanized coated metal sheet in the thickness of 0.5 mm
(Zn coating 180g/m2) and painted (Top-22
Size 5950mm(L)*2250mm (W)*2690 mm(H)(external size) 5700mm(L)*2020mm(W)*2390mm(H)(internal size)
Or6050mm(L)*2438mm (W)*2590 mm(H)(external size) 5875mm(L)*2255mm(W)*2325mm(H)(internal size)
Floor Composition external/internal wainscot: Flat galvanized coated metal sheet in the thickness of 0.5 mm
(Zn coating 180g/m2) and painted (Top side 10 μm) Steel sheet metal, in ASTM A653 CS
quality;insulation filling: mineral wool in a thickness of 100 mm (EN 13162, reaction to fire acc. to
EN 13501 Class 1) among steel transverse supports;steam blockade: PE foil in a thickness of 80 μm;
waterproof chipboard in a thickness of 22 mm – E1 (EN 120), type P5 ( EN 312);
glued final PVC floor covering in a thickness of 1,5 mm (EN 649),
Grey color with welded connections.
Ceiling Composition external/Internal wainscot: flat galvanized coated metal sheet in the thickness of 0.5 mm
(Zn coating 180g/m2) and painted (Top-22
