Specifications
1.Filtration accuracy: 1–100µm (common: 1, 3, 5, 10, 20, 60µm) Can be customized according to requirements
2.Outer diameter: Ø35–80mm (common 60mm)
3.Length: 100mm–1500mm or 5″, 10″, 20″, 30″, 40″
4.Filtration area: approximately 0.52m² (Ø50×975mm) to 9m² (large length size)
5.Maximum operating pressure difference: up to 4–20 bar at room temperature; typical 5 bar; withstand pressure of a model to 175MPa (=1750 bar)
6.Maximum service temperature: 300–480°C; some models can reach 600°C
7.Porosity: ≥70%, sintered felt filter element can reach up to 80%
8.Structural strength: The support core withstand pressure can reach 175MPa; the working pressure generally reaches 35MPa9.Sealing materials: Common materials of O-rings (silica gel, EPDM, NBR, Viton fluoride glue)
Advantages and Features
1.High strength & extreme environment resistance: suitable for high temperature and high pressure and corrosion media
2.Large flux & low pressure loss:
1.Filtration accuracy: 1–100µm (common: 1, 3, 5, 10, 20, 60µm) Can be customized according to requirements
2.Outer diameter: Ø35–80mm (common 60mm)
3.Length: 100mm–1500mm or 5″, 10″, 20″, 30″, 40″
4.Filtration area: approximately 0.52m² (Ø50×975mm) to 9m² (large length size)
5.Maximum operating pressure difference: up to 4–20 bar at room temperature; typical 5 bar; withstand pressure of a model to 175MPa (=1750 bar)
6.Maximum service temperature: 300–480°C; some models can reach 600°C
7.Porosity: ≥70%, sintered felt filter element can reach up to 80%
8.Structural strength: The support core withstand pressure can reach 175MPa; the working pressure generally reaches 35MPa9.Sealing materials: Common materials of O-rings (silica gel, EPDM, NBR, Viton fluoride glue)
Advantages and Features
1.High strength & extreme environment resistance: suitable for high temperature and high pressure and corrosion media
2.Large flux & low pressure loss:
Certificate
- ISO 9001
Main Products
Filter Housing, Filter Cartridge, Filter Element,Filter Bag.
