Features of product as follows:
Model LD electric Double -girder Overhead Crane is widely used in machine -processing ,
assembly workshop ,metallurgy ,casting workshop and warehouse ,etc,for loading and
unloading the goods .The configuration grap can be used in metallurgy ,cement ,chemical
industry and in the open air for loading and unloading the granular items with fixed span.
Technical Data
Lifting capacity(t) 1,2,3,5,10,16,20
Span (m) 7.5-22.5
Mechanism travelling Speed (m/min) 10 ,20, 30 45, 60
Motor Type ZDY21-4 ZDR12-4
Power(kw) 2*0.8 2*1.5
Speed (r/min) 1380 1380
Electric Hoist Model CD1/MD1
Lifting height 6,9,12,18,24,30
Lifting speed 8(7);8/0.8(7/0.7)
Traversing speed 20,30
Work Classification A3-A5
Power supply(v,Hz) 200V-600V ; 50Hz
Dia of wheel(mm) Ø300
recom mended rail P18 ,P22,P24,P30
Model LD electric Double -girder Overhead Crane is widely used in machine -processing ,
assembly workshop ,metallurgy ,casting workshop and warehouse ,etc,for loading and
unloading the goods .The configuration grap can be used in metallurgy ,cement ,chemical
industry and in the open air for loading and unloading the granular items with fixed span.
Technical Data
Lifting capacity(t) 1,2,3,5,10,16,20
Span (m) 7.5-22.5
Mechanism travelling Speed (m/min) 10 ,20, 30 45, 60
Motor Type ZDY21-4 ZDR12-4
Power(kw) 2*0.8 2*1.5
Speed (r/min) 1380 1380
Electric Hoist Model CD1/MD1
Lifting height 6,9,12,18,24,30
Lifting speed 8(7);8/0.8(7/0.7)
Traversing speed 20,30
Work Classification A3-A5
Power supply(v,Hz) 200V-600V ; 50Hz
Dia of wheel(mm) Ø300
recom mended rail P18 ,P22,P24,P30
Certificate
- ISO
- CE
