Features
1. Three-color LCD Backlight Display
2. 128 Momory Frequency Channels
3. Built-in VOX
4. Scan Function
5. Emergency Alarm
6. PC Programmable
7. Wide/Narrow Bandwidth Selectable
8. Keypad Lock
9. ANI Function(Optional)
10. Scrambler(Optional)
11. VOX Function
12. Squelch Level Selectable
13. Beep Function
14. Setting QT
15. Setting Offset Frequency
16. Offset Frequency Selectable
17. Frequency Step Selectable
Specifications
General Specifications
Frequency Range VHF:136-174MHz 230-260MHz UHF:350-390MHz 400-470MHz440-512MHz
Memory Channels 128
Channel Spacing 25/12.5KHz
Working Mode Co-channel or Dis-channel Simplex
Voltage DC 7.2V
Battery 1200mAh(Li-ion)
Average battery life(at 5/5/90 duty cycle with battery saver ) About 15 hrs
Frequency Stability ±2.5ppm
Operating Temperature -20°C/+50°C
Antenna Impedance 50Ω
Dimensions (H×W×D)(mm) (W/Battery,W/o Antenna) 100mm×55mm×32mm
Weight about 220g
Transmitter
Power Output VHF:5W/UHF:4W
Maximum Deviation ≤5KHz
