PRODUCT DESCRIPTION:
Four Core Anchor clamps are design to anchor self supporting LV.ABC from 2 to 4 cores, the wedge can be self-adjusting.Pilot wires or street lighting conductor are led alongside the clamp.The self opening is featured by an integrate sping facilities for easily insert the conductor into the clamp.
xANa-b
x : number of conductor outgoing.
a: min size of conductor
b: max size of conductor
B: branch, its for service twisted cable
W:OY:S:strain line
PRODUCT RANGE:
TYPE RANGE RATING WEIGHT PACKING NW DIMENSIONS
(kN) (kg) (PCS) (kg) (L*W*H)
2AN10.35 2x 10-35 6 0.077 260 19.5 48*34*35
4AN10.35 4x 10-35 6 0.118 160 19 48*34*35
2ANW10.35 2x 10-35 0.108
4ANW10.35 4x 10-35 0.118
2AN10.35 OY 2x 10-35 6 0.110
4AN10.35OY 4x 10-35 8 0.120
4AN10.120 4x 16-120 32 1.0055 24 24 45.5*35.5*18
4AN16.50 4x 16-50 15
4AN16.50S 4x 16-50 15
4AN10.120B 4x 16-120 +2x 10-35 32 1.183 24 26 51.5*35.5*18
USED MATERIAL:
Hi-conductivity aluminium UV&fire resistant plastic,hot di
Four Core Anchor clamps are design to anchor self supporting LV.ABC from 2 to 4 cores, the wedge can be self-adjusting.Pilot wires or street lighting conductor are led alongside the clamp.The self opening is featured by an integrate sping facilities for easily insert the conductor into the clamp.
xANa-b
x : number of conductor outgoing.
a: min size of conductor
b: max size of conductor
B: branch, its for service twisted cable
W:OY:S:strain line
PRODUCT RANGE:
TYPE RANGE RATING WEIGHT PACKING NW DIMENSIONS
(kN) (kg) (PCS) (kg) (L*W*H)
2AN10.35 2x 10-35 6 0.077 260 19.5 48*34*35
4AN10.35 4x 10-35 6 0.118 160 19 48*34*35
2ANW10.35 2x 10-35 0.108
4ANW10.35 4x 10-35 0.118
2AN10.35 OY 2x 10-35 6 0.110
4AN10.35OY 4x 10-35 8 0.120
4AN10.120 4x 16-120 32 1.0055 24 24 45.5*35.5*18
4AN16.50 4x 16-50 15
4AN16.50S 4x 16-50 15
4AN10.120B 4x 16-120 +2x 10-35 32 1.183 24 26 51.5*35.5*18
USED MATERIAL:
Hi-conductivity aluminium UV&fire resistant plastic,hot di
