atv Trailer

Product ID: RVT - 219

Send Inquiry
ALL OF OUR TRAILERS HAVE PATENT RIGHTS IN CHINA AND COPY RIGHT PROTECTED

Standard size:
6*12
* coupler2tailgate: 4700 mm (1100mm long drawbar from center of the front gate)
* fender2fender: 1845 mm (1790mm tray inside meas. )
Other available size:
1. 6*10
* coupler2tailgate: 4100 mm (1100mm long drawbar from center of the front gate)
* fender2fender: 1845 mm (1790mm tray inside meas. )
2. 6*14
* coupler2tailgate: 5350 mm (1100mm long drawbar from center of the front gate)
* fender2fender: 1845 mm (1790mm tray inside meas. )
Side panels:
* 300 mm
* 350 mm
* 400 mm
Tires: e-marked / DOT approved 13" / 14" / 15" high speed 4 / 6 ply rated
Wiring: 4 / 7 pin flat and round plug wiring with e-marked / DOT approved lights
Jack wheel / hitch: sae / DOT approved
Axle / hubs: ezi-lub axles with 4 / 5 bolt circle hubs galvanized / painted
Leaf springs: single eye slipper and double eye spring multiple leafs.
Brakes: hydraulic / disc / mechanical disc / electrical brakes all kind of brakes
Extras: tie downs, galvanized & paint.
Technical information:
Chassis: 50*50*5 mm angular
A-frame: 75*50*2. 5 mm tube
Tailgate: 1220 (4ft) height tailgate
Hitch: different hitch depend up on country requirements
Treated wood / mesh / checker plate flooring
Jack: a-frame jack with top wind / side wind.
Features
ATV TRAILER^$^#

Main Products

tandem trailer, tipping trailer, dumping trailer, box trailer
