Features:
1) Materials:
a) Terminal screw: brass, tin plated, 0.5t
b) Spring: stainless strip steel (SUS 301), 0.4t
c) Insulating body: polyamide 66 (UL94V-0)
d) Lever cover: polyamide 66 (UL94V-0)
2) Electrical parameters:
a) Voltage rating: 300V AC
b) Current rating: 10Amps/way (max.)
c) Insulation resistance: 5,000MΩ / 500V
d) Wire range: 14-24AWG
3) Operating temperature: -40 ~ +105oC
4) Safety approval: 2P-30P
