Brand: VONYE
Features
- Polyamide 6(PA6) (Nylon 6), meets UL 94 V2.
- PF thread
- Light
- Weather resistant.
- Temperature range: -10°C~+120°C.
- IP67.
- Color: black, gray
- RoHS & REACH compliant
- Straight type B7439 is available.
| Catalog number Black |
Catalog number Gray |
Trade size (inch) |
A (mm) |
B (mm) |
C (mm) |
D (mm) |
E (mm) |
F (mm) |
Thread | Suit for cable size (mm) | Packing (pcs) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| L74390306 | L75390306 | 3/8" | 28.0 | 44.0 | 13.0 | 21.0 | 20.0 | 32.0 | PF 1/2 | 6 - 8 | 50 |
| L74390309 | L75390309 | 3/8" | 28.0 | 44.0 | 13.0 | 21.0 | 20.0 | 32.0 | PF 1/2 | 9 - 12 | 50 |
| L74390312 | L75390312 | 3/8" | 28.0 | 44.0 | 13.0 | 21.0 | 20.0 | 32.0 | PF 1/2 | 12- 15 | 50 |
| L74390615 | L75390615 | 3/4" | 39.0 | 52.0 | 13.0 | 26.4 | 25.0 | 40.0 | PF 3/4 | 15 - 18 | 25 |
