• Many optional devices such as a notch cutter, a continuous perforation knife and an adjustable conveyor.
• Accurate cutting.
• Quiet operations.
• Easy to operate.
• PLC with color touch screen control system.

Specification:

• Speed 40 m/min
• Max Cuts per minute 400
• Max Draw 900 mm
• Available Widths 300/400/500 mm
• Unwind Diameter 700 mm
• Core Diameter 3”(76mm)
• Accuracy 0.1mm

Standard Specifications:

• PLC Based Control System Operator
• Touch Screen Operator Interface
• AC Vector Drives- Infeed & Main (Knife & TD Perforation)
• Servo Motor
• Multicolor Photo Sensor
• TD Perforation Station -90& 75 T-Perfs
• Cantilever 3”(76mm) Unwind Air Shaft
• Adjustable Conveyor
• Static Eliminator
• Dancer System – Unwind Tension
• Unwind Magnetic Powder Brake
• Spare Cutting Knife

Optional:

• Continuous Perforation
• Jaw Cutting Device(Tear Tab)
• Rewind with Oscillation
• Stand Alone Unwind with EPC
• Double cut System
