Thermoforming Egg Carton/Box/Clamshell Labeling Machinel

Thermoforming Egg Carton/Box/Clamshell Labeling Machinel

Click here for details.

321-VA-EGAA-S4BC Automatic Thermoforming Egg Carton/Box/Clamshell Labeling Machine

Product ID: Plastic Thermoforming Egg Carton/Box/Tray/Clamshell Labeling 321-VA-EGAA-S4BC Series (153)

Send Inquiry

Model: 321-VA-EGAA-S4BC

♦ Pressure Sensitive Self-adhesive Type of Label

♦ Twin-Head Labeling System

♦ For Plastic Vacuum /Thermoforming Egg Carton/Tray/Clamshell

♦ Automatic Continuous Supplementary Feeding

♦ No Need to Stop the Machine For Re-filling

♦ Automatic Pre-Set Quantitative Separation

♦ Batched Quantity Automatic Collecting System

■ Product Example:

- 6-Cell Egg Carton/Box/Tray

- 10-Cell Egg Carton/Box/Tray

- 12-Cell Egg Carton/Box/Tray

- 15-Cell Egg Carton/Box/Tray

- 2 * 6-Cell Egg Carton/Box/Tray

- 30-Cell Egg Tray Lid

- Clamshell

- Food Container

- Fruit Box

Specifications
■ Specification: • Labeling Speed: Approx.40 pieces/min• Reference Labeling Product:• Lay-Flat 145 ~ 150 (L)*220 (W) mm• Main Label: Max. 200 (L)*160(H) MM Included Base Paper• Strip Label: Max. 200 (L)*13(H) MM Included Base Paper• Label Roll: Ø 300 (O.D.)*76 (I.D.) mm• Machine Size: Approx.5000 (L)*900 (W)*1450 (H) mmModel 311-VA-EGAA-S3BC for single main label type is also available.
Features
■ Control System:• Japan "MITSUBISH" PLC Control System. • Japan "YASKAWA" Servo Motor Control System. • Interfaced 10" Colorful HMI Touch Screen Monitor. • Label Sensor: "SICK" Optoelectronic Sensor. • Product Detect Sensor: "OMRON" Optoelectronic Sensor.

Main Products

UNIMAX GROUP plastic & packaging machinery department offer a wide range of plastic processing, labeling, assembly, lining machines and packaging automation for different industries. The tissue paper machinery department offer superior converting, wrapping and packaging machines for tissue industry.
